MistBuster 2000

A high-capacity electrostatic mist and smoke collector built for CNC machining, grinding, and EDM. It features advanced multi-stage filtration, energy-efficient performance, and flexible mounting options to remove airborne contaminants and maintain compliance with industrial air quality standards.

The Tri-Mist® 1000 is a compact, high-efficiency air filtration unit designed for mist and smoke collection in precision metalworking environments, including CNC machining, EDM, and grinding. It employs a triple-pass electrostatic precipitation (ESP) system featuring solid-state, self-regulating power supplies and high-voltage collector cells operating at up to 20,000 volts/inch. This advanced configuration enables efficient capture of submicron aerosols and oil-based particulate without reliance on consumable filters. A multi-stage impingement and post-filtration setup further enhances contaminant removal. With airflow adjustable up to 1,000 CFM and energy consumption under 450 watts, the unit ensures optimal source capture performance, reduced maintenance, and compliance with OSHA and ASHRAE indoor air quality standards.

Available in 115V, 208-230V, 340-480V models. Price reflects 115V model. Contact us for additional pricing.

FEATURES:
Triple-Pass ESP Technology: Provides high-efficiency mist and smoke removal without disposable filters
Energy-Efficient Operation: Operates on less than 450 watts
Compact Design: Allows for direct mounting to machine tool enclosures
Versatile Installation Options: Optional flex-duct and inlet plenum for ceiling, wall, or floor-mount installations
Low Maintenance: Reduces operating costs and downtime
Performance Guarantee: Satisfaction guaranteed with a return policy
Warranty: 48-month limited warranty, the longest in its class

SPECIFICATIONS:
Airflow Capacity: Adjustable from 50 to 1,000 CFM
Filtration Efficiency: Up to 99% per ASHRAE 52.2
Filtration Stages:
Two 2″ mechanical impingers
Three ESP cells, each with 53 sq. ft. of surface area (minimum voltage gradient of 20,000 volts per inch)
1″ thick post filter
Optional 6th stage HEPAMAX filter rated at 99.97% DOP @ 0.3 micron
Power Input: 115 V, 60 Hz, 4 amps; 208–230 V, 50–60 Hz, 2 amps; 380–480 V, 50–60 Hz, 1 amp
Power Consumption: Less than 450 watts
Cabinet Construction: 16-gauge steel welded with chemical-resistant powder paint
Inlet Opening: 16.70″ x 9.10″
Sound Level: 69 dB(A)
Impeller: Vibration-free, backward-curved, rated at 1100 CFM @ 0.0″ w.g.
ESP Power Supply: Solid-state and self-regulating
